    High Pressure 10 Inch Sd10 Dth Water Hammer Forging

    Ask Lasest Price
    Brand Name : GLORYTEK
    Model Number : High pressure DTH Drilling Hammers
    Certification : CE,SGS,TUV
    Price : To be negotiated
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 2000 sets per month
    Delivery Time : 5-7 workdays
    • Product Details
    • Company Profile

    High Pressure 10 Inch Sd10 Dth Water Hammer Forging

    High pressure 10 inch DTH hammer bits diamond drilling bits manufacturer


    1.Description:
    -We have rich experience in this field of DTH hammers and bits for more than 20 years.
    Owing to high quality, professional serivce and competitive price, we have gotten good reputation from our customers from all over the world, such as France, Spain, Italy, South Africa, Iran, Malaysia, Australia ad etc.

    -Most DTH hammers are designed for use with the industry's most common rock drill bits shank types such as DHD, QL, Cop, Mission, SD, and so on.


    -Selection of high-quality raw materials and advanced processing technology, more stable performance, longer life. The domestic advanced heat treatment process is adopted to ensure the good mechanical properties of the hammer.


    2.Applications:

    Versatile DTH hammers to interchangeable, or replace a number of leading industry manufacturers. Hammers are available for down hole and blast hole, water well, gas, mining applications and use in nearly all ground conditions.


    3.Specifications:

    Type and Technical Specification of High Pressure DTH Hammers
    ItemGL330GL335GL340AGL345GL350GL355GL360GL380GL3120
    Drilling Dia. (ф/mm)82-8590-93105-130105-130130-152130-152152-305203-350302-508
    Hammer Length(mm)8679081052103413871220145015511934
    Outside Dia. (ф/mm)71819298114124136181275
    Weight(kg)1921.838396974126277642
    Working Pressure(Mpa)0.8-2.10.8-2.10.8-2.10.8-2.10.8-2.10.8-2.10.8-2.10.8-2.10.8-2.1
    Air Consumption (M3/Min.)3-124.3-14.23.5-183.5-155.7-186.5-188.5-2512-3114-45
    Torque(N.M)15020530433559070082215602410
    Impact Frequency (Times/Min.)≥800950-1500≥800≥800810-1470810-1500820-1475860-1510980-1446
    Connection 148.8×4.2API 2-3/8API 2-3/8API 2-3/8API 3-1/2API 2-3/8API 3-1/2API 4-1/2API 6-5/8
    Connection 2ф47-6ф53-8ф64-8ф64-8ф84-8ф84-8ф99.5-8ф128-10ф184-8

    Hammers
    Bit ShankConnection ThreadSuitable bitWorking pressureAir consumption
    1-3" Middle-low pressure DTH hammers
    BR1
    BR2
    BR3
    RD40 box
    RD50 box
    API 2 3/8" Reg

    ¢64-¢76mm
    ¢70-¢90mm
    ¢90-¢110mm
    0.7-1.75Mpa
    0.7-1.75Mpa
    0.7-1.75Mpa
    0.7Mpa4.5m3/min
    1.0Mpa4m3/min
    1.4Mpa5m3/min
    3" hammersDHD3.5
    COP32/COP34
    M30
    API 2 3/8"Reg¢90-¢110mm1.0-1.5Mpa1.0Mpa4.5m3/min
    1.5Mpa9m3/min
    4" hammersDHD340
    COP44
    QL40
    SD4
    M40
    API 2 3/8"Reg¢105-¢130mm1.0-2.5Mpa1.0Mpa6m3/min
    1.8Mpa10m3/min
    2.4Mpa15m3/min
    5" hammersDHD350
    COP54
    QL50
    SD5
    M50
    API 2 3/8"Reg/API 3 1/2"Reg¢130-¢156mm1.0-2.5Mpa1.0Mpa9m3/min
    1.8Mpa15m3/min
    2.4Mpa23m3/min
    6" hammersDHD360
    COP64
    QL60
    SD6
    M60
    API 3 1/2"Reg¢152-¢203mm1.0-2.5Mpa1.0Mpa10m3/min
    1.8Mpa20m3/min
    2.4Mpa28.5m3/min
    8" hammersDHD380
    COP84
    QL80
    SD8
    API 4 1/2"Reg¢200-¢279mm1.0-2.5Mpa1.0Mpa15m3/min
    1.8Mpa26m3/min
    2.4Mpa34m3/min
    10" hammersSD10
    NUMA100
    API 6 5/8"Reg¢254-¢330mm1.0-2.5Mpa1.0Mpa22m3/min
    1.8Mpa40m3/min
    2.4Mpa55m3/min
    12" hammersDHD1120
    SD12
    NUMA120
    NUMA125
    API 6 5/8"Reg¢305-¢381mm1.0-2.5Mpa1.0Mpa30m3/min
    1.8Mpa56m3/min
    2.4Mpa78m3/min


    Related Product
    Drilling tools, like DTH hammers and bits, DTH drill pipes, RC hammers and bits, tophammer button bits, coupling, cross bits, drill rods.
    Drilling rig,like water well drilling rig,HDD drilling rig,Rock drilling rig,Core Drilling rig,HDD drilling rig etc.


    Company Profile

    High Pressure 10 Inch Sd10 Dth Water Hammer Forging
    High Pressure 10 Inch Sd10 Dth Water Hammer Forging


    Glorytek Industry ( Beijing) Co., Ltd is a professional manufacturer and supplier of drilling equipment and drilling tools with over 20 years experience. We are supported and assisted by highly experienced R & D team and engineers that enable us to complete all the assigned projects successfully as per clients’ requirements.


    Our factory covers an area of 250,000 square meter, construction area is about 150,000 square meter, having machining machinery, CNC processing center, friction welding machine, testing equipment etc. over 200 sets and more than 600 employees.Our products have been exported more than 60 countries around the world.
