DTH Drilling Hammer DHD360 Water Well Drilling Tool Without Foot
Valve
Description
DTH hammers are used in various down the hole operations like bench
Drilling.
Our DTH hammer and bits are compatible with CIR, DHD,
QL,SD,Mission, etc. series of Atlas and Sandvik etc. They are with
high efficiency, low failure rate and long service life. Even for
all kinds of high hardness, high abrasive rocks and other harsh
conditions, our drilling tools can also realize efficient and
economical drilling.
Selection of high-quality raw materials and advanced processing
technology, more stable performance, longer life. The domestic
advanced heat treatment process is adopted to ensure the good
mechanical properties of the hammer.
Technical Parameter
High Pressure DTH Hammers |
Item | GL360SK |
Drilling Dia. (ф/mm) | 165-219 |
Hammer Length(m) | 1372 |
Outside Dia.(ф/mm) | 152 |
Weight(kg) | 92 |
Working Pressure(Mpa) | 0.8-2.1 |
Air Consumption (m3/min) | 43734 |
Torque(N.M) | 1150 |
Impact Frequency (Times/Min.) | 950-1650 |
Connection 1 | API 3-1/2 |
Connection 2 | Ф99.5-8 |
Applications
DTH hammers are widely used for mine, quarry, road construction for
the drilling and blasting work, water well drilling, slope
protection, anchoring, etc.
Features
1. Smooth performance and long service life of DTH hammer due to
high quality alloy steel materials and advanced processing
technology adapted.
2. Low problem rate and easy to maintenance due to simple, reliable
and easy assemble and disassemble inner structure of hammer.
Packing
Packing: wooden box.
Delivery: Normally 5-7 days after down payment.
Shipping method: by express, by air or by sea
