    Multipurpose 300m Drill Rig Machines For Borehole Air Mud Drilling

    GL300S Borehole 300m Air And Mud Drilling Drill Rig Machines


    Description:

    GL300S water well drilling rig is a lightweight, efficient and multifunctional drilling equipment.

    It is mainly applicable to industrial and civil drilling, geothermal drilling.

    Drilling depth can reach 300m
    Steels quality is good, torque is large

    It can use 3m, 6m length drill pipes.

    It is especially suitable for mountain and rock formation water intake projects.

    Our drilling rigs are more efficiency and with low failure rate, more economic and durable, and with a high comprehensive cost performance.


    Tehnical Parameter:

    Technical Parameter
    Max drilling depth330m
    Drilling diameter105-300mm
    Air pressure1.25-3.5Mpa
    Air consumption16-55m³/min
    Rod length3m/6m
    Rod diameter76/89/102mm
    Main shaft pressure6T
    Lifting force20T
    Fast lifting speed20m/min
    Fast forwarding speed40m/min
    Rotary torque8900 N.M
    Rotary speed30/170r/min
    Weight of the rig7.8T
    Dimension4.9m x 2m x 2.3m
    Working conditionloose layer or bedding rock
    Suitable hammerMedium and high pressure DTH hammer
    Optional accessoriesMud pump, centrifugal pump, generator, foam pump
    Diesel Engine77KW(Yuchai)


    Customer Visting

    Company Profile

    Glorytek Industry ( Beijing) Co., Ltd is a professional manufacturer and supplier of drilling equipment and drilling tools with over 20 years experience. We are supported and assisted by highly experienced R & D team and engineers that enable us to complete all the assigned projects successfully as per clients’ requirements.
    Glorytek Drill is one of the most important member of “Sundrill Corporation”.Our factory covers an area of 250,000 square meter, construction area is about 150,000 square meter, having machining machinery, CNC processing center, friction welding machine, testing equipment etc. over 200 sets and more than 600 employees.Our products have been exported more than 60 countries around the world.
