Product Description:
Our Drill Rig Machines are engineered to climb slopes with ease,
thanks to their impressive slope climbing ability of 25 degrees.
This feature allows our machines to reach higher altitudes and
access difficult terrains with minimal effort, improving the speed
and accuracy of drilling operations.
Our machines have a rotation speed of 0-80 rpm, making them capable
of handling a wide range of drilling tasks. The high rotation speed
ensures that the drill bit can penetrate hard rock surfaces easily,
making our machines ideal for mining and quarrying operations.
The Drill Rig Machines have a ground clearance of 420 mm, which
allows them to navigate through rough terrain with ease. The high
ground clearance also helps to prevent damage to the machine when
travelling through uneven surfaces, improving the durability and
longevity of the machine.
The dimensions of our machines are 12,560x2,700x3,560 mm, making
them compact and easy to manoeuvre. The compact size of the
machines also makes them ideal for working in confined spaces,
ensuring that drilling operations can be carried out in areas that
are difficult to access.
Our Integrated DTH Drill Rig is the perfect choice for blasthole
drilling operations. Whether you're working in mining or quarrying,
our machines are designed to deliver maximum productivity,
reliability, and efficiency. So, if you're looking for a
high-performance Surface Integrated Drilling Rig, look no further
than our Drill Rig Machines.
Technical Parameters:
| Product Type | Surface Drill Rig |
| Dimensions | 12,560x2,700x3,560 mm |
| Drill Pipe Length | 7 m (Optional 5 / 6 m) |
| Drill Pipe Handling Capacity | 4+1 |
| Maximum Hole Depth with Auto Handling | 35 m |
| Capacity FAD | 33 m3 / min |
| Recommended DTH Hammer Size | 6" (Optional 7"/8") |
| Maximum Working Pressure | 25 bar (362.5 psi) |
| Fuel Tank Capacity | 1,000 L |
| Drill Pipe OD | 114 mm (Optional 102 / 127 mm) |
| Ground Clearance | 420 mm |
| Product Type | Integrated DTH Drill Rig |
| Product Type | DTH Drill Rig |
Applications:
Support and Services:
Installation and commissioning
Maintenance and repair
Spare parts and consumables
Remote monitoring and diagnostics
Our team of experienced technicians and engineers are available to
provide on-site support and assistance, as well as remote support
via phone or email. We also offer customized service agreements to
meet your specific needs and budget.
