Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine

Glorytek Industry (Beijing) Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine from wholesalers

    Buy cheap Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine from wholesalers
    • Buy cheap Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine from wholesalers

    Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine

    Ask Lasest Price
    Brand Name : Glorytek
    Model Number : option
    Certification : CE and others
    Price : 350000-390000USD Per set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 15 set per month
    Delivery Time : 25-35days
    • Product Details
    • Company Profile

    Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine

    Top Hammer Rock Drilling Rig

    The track oscillation system makes the center of gravity of the drill rig more stable to climb the slopes up and down,with stronger track tradion.The protection design of the cab and drill rod carousel protect personnel from possible danger;
    The rig can drill multiple rock holes in single positioning action. The flexible drilling arm and off-road ability meet complex rock drilling requirements. For hole diameter <115 mm, hole depth is less than 15 m, the drilling speed is 50% faster than high pressure integrated DTH drilling rig;

    Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine

    Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine

    Technical Parameter

    Main Specifications

    T640J

    Drifter Model

    ZY-104H

    Hole range

    76-102 mm

    Drill rod

    T45(T51)x3,660 mm

    Hole depth

    22 m

    Max. impact power

    20 kW

    Model

    4BTA3.9-C125- II

    Rated power

    93 kW

    Speed

    2,200 rpm

    Fuel tank capacity

    280 L

    Diesel Engine

    Cummins 152 kW

    Feed / Pull up force

    20 kN / 20 kN

    Rod changer and #S of rods stored

    5+1(Auto)

    Air Compressor Air consumption

    7 m3/min

    Air Compressor pressure

    8 bar

    Max. climbing ability

    25°

    Track frame oscillation

    ±10°

    Max. traction force

    69 KN

    Total Weight

    14,100 kg

    Packing and Transport

    1. Drilling machine is bare packing.

    2. Drilling tools will be packed in cases or wooden boxes.

    3.The delivery time for machine normally be 25-35 days after receiving payment. The drilling tools normally 3-5days if in stock.

    4. Shipping by sea, air or express are all available.

    Company Profile
    Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine
    Glorytek Industry (Beijing) Co., Ltd. is an integrated corporation specialized in manufacturing and exporting top quality drilling equipment and drilling parts for more than 20 years. We are supported and assisted by highly experienced R&D team and enginners that enable us to complete all the assigned projects successfully as per clients; requirements.
    Our factory covers an area of 250,000 square meters, construction area is about 150,000 square meters, having machining machinery, CNC processing center, friction welding machine, testing equipments etc. over 200 sets and more than 600 employees.
    Our products have been exported more than 60 countries, including Australia, Russia, Soutn Africa, Zimbabwe, Malaysia, Indonesia, South Korea, France, Sweden, USA, Canada, Haiti etc.
    Customer Visit
    Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine
    Exhibition
    Rock Drill Rig T640J Top Drive Hammer Mining Drilling Rig Quarry Drill Machine
    FAQ
    Q: How can we choose a suitable water well drill rig?
    A: We normally recommend a suitable model according to drilling depth, drilling hole dia. and layer condition on site.
    Q: Are you a factory or a trading company ?
    A: We are an integrated corporation specialized in manufacturing and exporting.

    Q: What is your payment terms?
    A: We can accept T/T,L/C.

    Q:.What is your MOQ? How long is the delivery time?
    A: Our MOQ is 1 sets. Normally for drill rig, the delivery time is about 25-30 days after receiving payment, the drilling tools would be about 3-5 days.

    Q:. How long is the warranty?
    A: The guarantee period for mainframe is one year (excluding the quick wear parts).

    Q: Can we print my Logo on the products?
    A: Yes, we can. We support OEM .
